946
Model Code Page
61. Steering system
6000--8950 610 18
1. 10. 1999
Steering wheel column
B --- B
A --- A
Lever, steering wheel heigth.
P edal, steering wheel angle
45 Nm
The steering axle lower end must
be 13---14 mm inside the steering
valve.
10 Nm
50 Nm
Locking of joint
pins.
Pedal control rod
Steering valve
