Build---up of Carraro axle is shown in pictures on the
following pages.
The maintenance intervals and oil qualities are the same
as in Sige---axle. However, the grease nipples of the
king pins are greased at intervals of 50 running hours/
weekly.
1012
Model Code Page
67. Powered front axle Carraro
1. 10. 1999
8450--8950 670 4
Description
Carraro 20.29 axle replaces the earlier used Sige industrial
front axle from week 32/99. The Carraro axle has as stan-
dard an electro---hydraulically controlled differential lock
(HiLock), which functi ons simultaneously with the rear axle
lock.
Earlier used front wheel discs cannot be use d with this Car-
raro---axle, since the front wheel fixing studs are different.
Picture 1. Carraro front axle
1. Axle housing oil draining plug
2. Filling plug
3. Hub oil draining / filling plug
4. EP ---grease on splines
