1020
Model Code Page
67. Powered front axle Carraro
1. 10. 1999
8450--8950 672 2
B. Changing hub cassette seal/wheel
bearings
1. Remove the planetary carrier (hub cover) as shown in
instr. 1A stages 1 --- 5 on page 672/1.
2. Support the hub with a lifting rope. Remove the drive
shaft snap ring and thrust washers. Observe the positions
of the washers.
3. Unscrew the ring gear support bolts (F). Screw in two
bolt s into puller holes (G) and pull out the ring gears.
4. Remove the ring gear and its support.
5. Remove the hub flange with wheel bearings and the cas-
sette seal. Remove the outer wheel bearing.
6. Remove the inner wheel bearing on the knuckle housing,
if damaged. Removing can be done with a drift and a puller.
7. Prise out the hub cassette seal.
