722
Model Code Page
42. Gearbox
8. 11. 1990
6000--8750 423 18
9. Fasten the brake cylinders. Connect the hand brake cable
wire. Fit the breather filter (work through the mudguard ope-
ning).
10. Connect the hydraulic power lift sensor connector s in the
leverconsoleinthecab.Fitalsothewirelead---inplate.
11. Connect the solenoid valve connector on the rear LH side.
Connect the sensor wires to the servo valve block on the LH
side of the gearbox. Connect the oil pipes on the LH side of
the gearbox.
12. Connect the propeller shaft rear flange joint. Fit the guard.
Fit the floor hatch and mat, if removed.
13. Lower the cab rear end and fasten the cab rear attach-
ments.
14. Fit the PTO unit (see instr. 462 1G).
15. Check that all hydraulic pipes have been fitted. Fit the
hatch plate onto the mudguard opening and fit the rear wheel.
Removethesupportplatesonthefrontaxle.Removetrestles
under the tractor.
16. Fit the engine hood plates. Fill the transmissi on with oil.
Connect the pick---up hitch release cont rol, levelling screw
joint and the PTO control cable (at the rear of the tractor).
17. Test---drive the tractor and check for oil leaks.
Note! On E---models, ensure that the AC---III/IV unit sensor
wires have been connected and check the function of the
AC---III/IV unit.
