Model ATRT-03 (v) Operating Instruction
17
8.0 ATRT-03/03A Printer and Printer Paper
The ATRT-03/03A consists of a built-in thermal printer which uses 4.5-inch wide thermal paper
for printing test results. To maintain the highest quality test-result printing and to avoid paper
jamming, the use of paper supplied by our factory is highly recommended. Additional paper can be
ordered from either of the two sources listed below:
Vanguard Instruments Co, Inc.
1710 Grevillea Court
Ontario, CA 91761
Tel: 909-923-9390
Fax: 909-923-9391
Part Number: TP-4 Paper
OR
BG Instrument Co.
13607 E. Trent Ave.
Spokane, WA 99216
Tel: 888-244-4004
Fax: 509-893-9803
Part Number: TP-4 paper
9.0 ATRT-03/03A/03B Storage Capabilities
9-1. ATRT-03/03A/03B Test Record Storage Capabilities
The ATRT-03/03A/03B is capable of storing up to 200 transformer test records. These test records
are stored in the FLASH EEPROM. Users can retrieve these records from the FLASH EEPROM
to be either printed by the thermal printer or transferred to a PC.
9-2. ATRT-03/03A/03B Transformer Test Plan Storage Capabilities
Each ATRT-03/03A/03B is capable of storing up to 128 Transformer Test Plans in the FLASH
EEPROM. A test plan allows the user to run a complete transformer test to obtain PASS or FAIL
results.
10.0 ATRT-03/03A/03B Operating Voltages
10-1. ATRT-03/03B Operating Voltages
The ATRT-03 and ATRT-03B operating voltages are selectable between 110/220 V, 50/60 Hz or
220/240, 50/60 Hz. Voltage selection is set by the reference transformer jumpers as shown in Table
10-1.
Table 10-1. Voltage-Selection Jumper Pins
VOLTAGE SELCTION TRANSFORMER
110/220 Vac Pin 1 & 2, 3 & 4
220/240 Vac Pin 2 & 3
Note:
Operating voltage is preset from the factory.
