Model ATRT-03 (v) Operating Instruction
60
#1 SINGLE PHASE
RATIO mA %DIFF
+100.00 0.00 0.00
Figure 19-1C. Scroll Test Record LCD Display Third Screen
Note:
1. The first line of the screen displays the test number. In the example above, the display is
showing the test results from test #1 of the record.
2. The second line of the screen displays the test result.
3. Use the “∧” and “∨” key advance to the next screen.
4. Use “STOP” key to return to main menu.
