Vanguard Instruments ATRT-03 - Figure 17-2. Print Directory Menu; Print Test Record Directory Menu

Model ATRT-03 (v) Operating Instruction
51
17-2. Print Test Record Directory Menu
PRINT DIRECTORY
1.FULL DIRECTORY
2.SHORT DIRECTORY
Figure 17-2. Print Directory Menu
a. Description: From the “Print Directory” menu, the user can print a short directory or long
directory. Short directory selection will print the last 10 record headers in FLASH EEPROM. Long
directory selection will print all test record headers in FLASH EEPROM.
b. Origin: From the “Start-Up” Menu (see Figure 14-1), press key 2 (SET UP). Press key 3
(RESTORE RECORD). Press key 2 (DIRECTORY).
c. Action Option:
1. Press key 1 (FULL DIRECTORY) to print all test record headers.
2. Press key 2 (SHORT DIRECTORY) to print the last 10 test record headers.
