14-13. Append This Reading Menu
PREVIOUS DATA IN BUF.
09/01/00
1. APPEND PREV. DATA
2. CLEAR PREV. DATA
Figure 14-13. Append Transformer Ratio Reading Menu
1. Description: This menu will appear only once at the end of a new test and only when the user is
running the same type of transformer test. For example, the last test the user ran was a “Delta to
Wye” test before powering down the unit. The user is now running another “Delta to Wye” test.
The ATRT-03/03A/03B will present this menu after the first result displayed. The user can append
this new test results to the previous test results still residing in the scratch pad memory.
This feature is handy when the user has to stop a test on a transformer. The user can continue the
test instead of having to repeat the entire test from the beginning.
2. Origin: The menu will appear if the user selects “YES” from the “KEEP THIS READING”
menu (Figure 14-12).
3. Action Option: Select key 1 to append this reading to other test results in scratch pad memory.
Select key 2 to store this reading in scratch patch memory only.
