Model ATRT-03 (v) Operating Instruction
58
19.0 Restore a Test Record to LCD.
The following steps allow the user to restore a test record from FLASH EEPROM and to be viewed
on LCD.
Table 19-1. Restoring a Test Record to LCD
STEP DESCRIPTION DISPLAY ACTION
1 Select “Set Up”
1.TEST XFMR 04/12/00
2.SETUP 13:06:00
3.CALCULATOR
4.DIAGNOSTIC
Press key 2
2 Select “Restore Record”
1.ENTER XFMR ID
2.REVIEW RECORD
3. RESTORE RECORD
4.NEXT PAGE
Press key 3
3 Select “Restore Record”
1.RESTORE RECORD
2.DIRECTORY
3.ERASE RECORD
Press key 1
4 Restoring a test record using record
number
RESTORE RECORD
1.ENTER RECORD NUMBR
2.SCROLL TO SELECT
Press key 1
5 Enter record number
RESTORE RECORD
NUMBER:
“ENTER” TO CONFIRM
Use key 0-9 to
enter record
number
6 Confirm record number
RESTORE RECORD
NUMBER:
“ENTER” TO CONFIRM
Press “ENTER”
key
7 Record recalled to memory
RECORD RESTORED!
Press any key
8 Select Print Record on thermal
printer
REVIEW RECORD
1.SCROLL TEST RECORD
2.PRINT TEST RECORD
Press key 1
9 View Test Record ID
(Note)
RECORD ID INFO:
ONTARIO AIRPORT
220KV EAST
GE
Press “ENTER”
key
10 View Transformer type, number of
taps, time and date
SINGLE PHASE XFORMER
2 TAPS
07/16/00 12:01:00
Press “ENTER”
key
11 View Tap #1 Ratio, mA, %DIFF
Advance to next tap
#1 SINGLE PHASE
RATIO mA %DIFF
+100.00 0.00 0.00
Press “ENTER”
key to advance
or “STOP” to
end
