Model ATRT-03 (v) Operating Instruction
82
26.0 ATRT-03/03B Test Voltage Selections
The following steps allow the user to select a test voltage.
Table 26-1. Select Test Voltages
STEP DESCRIPTION DISPLAY ACTION
1 Select “Set Up” menu
1.TEST XFMR 04/12/00
2.SETUP 13:06:00
3.CALCULATOR
4.DIAGNOSTIC
Press key 2
2 Select “Next Page” menu
1.ENTER XFMR ID
2.REVIEW RECORD
3.SAV/RES RECORD
4.NEXT PAGE
Press key 4
3 Select “Set Test Voltage” menu
1.COMPUTER CONTROL
2.SET TIME
3.SET TEST VOLTAGE
4.TEST PLANS
Press key 3
4 Select 8 Vac test voltage.
(Note 1)
SELECT TEST VOLTAGE
1. 8V (CT TEST)
2. 40V (NORMAL TEST)
3. 100V (NOISY ENV.)
Select 1
5 Confirm Test Voltage
TEST VOLATGE SET TO
8 VOLTS RMS
Press ENTER
key to confirm
Note:
1. The ATRT-03/03B will default to 40 Vac test voltage when power is first applied to the unit.
Once the new test voltage is selected, this voltage will be active until a new voltage is selected.
2. The ATRT-03A uses 20 Vac test voltage.
