Model ATRT-03 (v) Operating Instruction
26
Table 14-0. Single-Phase Transformer Test Procedure Steps (cont.)
STEP DESCRIPTION DISPLAY ACTION
13 Store reading in buffer
KEEP THIS READING?
1.YES
2.NO
Press key 1
13A If first time saved
TEST SAVED
Press any key
14 Clear previous results in
buffer before saving data.
PREVIOUS DATA IN BUF.
09/01/00
1.APPEND PREV. DATA
2.CLEAR PREV. DATA
Press key 2
15 End test
RUN ANOTHER TEST?
1.YES
2.NO
Press key 2
16 Store Test Results in FLASH
EEPROM
SAVE THIS RECORD?
1.YES
2.NO
Press key 1
17 Test Results Saved in
FLASH EEPROM
confirmation
RECORD NUMBER 3
HAS BEEN SAVED
Press any Key
18 Return to main menu
1.TEST XFMR 04/12/00
2.SETUP 13:06:02
3.CALCULATOR
4.DIAGNOSTIC
None
Note:
When starting a new test, the user can append the new test results to previous test results stored in
scratch-pad memory. This feature is handy in a situation where the user is running a test and has to
terminate the test. Later, the user can continue the test from where it was left off instead of
repeating the entire test from the beginning. Refer to section 14-13 for more details.
