Model ATRT-03 (v) Operating Instruction
28
14-2. Test Transformer Selection Menu
XFRMER CONFIGURATION:
1.SNG PHS 2.dT-Y
3.Y-dT 4.dT-dT
5.Y-Y 6.SP TEST
Figure 14-2. Transformer Selection Menu
a. Description: This menu allows the user to select a particular transformer to be tested.
b. Origin: XFRMER CONFIGURATION menu display as a result of pressing key 1 from the
“Start-Up” menu (see Figure 14-1).
c. Action Option: Press key 1, 2, 3, 4, 5 or 6 depending upon the transformer configuration to be
tested. Press STOP to return to the “Start-Up” menu.
Note:
1. The ATRT-03/03A/03B will support 36 “Non-Standard Transformer” type tests. These “Non-
Standard Transformer” tests are identified under special test (selection #6 of Figure 14-2).
2. Non-Standard Transformer configurations are shown in Appendix B.
