Model ATRT-03 (v) Operating Instruction
69
21-1. Load Test Plan Menu
LOAD TEST PLAN
1.ENTER PLAN NUMBER
2.SCROLL TO SELECT
Figure 21-1. Test Record Menu
a. Description: The ATRT-03/03A/03B Test Plan from FLASH EEPROM is loaded to memory to
be used for testing a transformer. The user can select the Test Plan by entering Test Plan number or
Scroll through the directory.
b. Origin: From the “Start-Up” menu (see Figure 14-1), press key 2 (SET UP). Press key 4 (NEXT
PAGE). Press key 4 (TEST PLAN). Press key 4 (LOAD TEST PLAN).
c. Action Option: Press key 1 to enter the Test Plan number. Press key 2 to scroll to Test Plan.
2 SNG PHS TAPS: 2
GE
14-445
JUST A TEST
Figure 21-1A . Typical Test Plan Header
Note:
1. Test number residing in memory is #2. (The user can store up to 128 test-plan in FLASH
EEPROM).
2. The transformer type is Single Phase.
3. There are 2 taps in this test plan.
4. Transformer manufacturer is “GE”
5. Transformer type is “14-445”
6. Special user comment on this test: “JUST A TEST”
To Next Page
