Model ATRT-03 (v) Operating Instruction
62
20-1. Printing Test Plan Menu 1
1.LOAD TEST PLAN
2.UNLOAD TEST PLAN
3.PRN TST PLAN DIR.
4.PRINT TEST PLAN
Figure 20-1. Test Plan Menu 1
a. Description: From the “Test Plan” menu, the user can:
1. Load a Test Plan from FLASH EEPROM to be used in a test.
2. Unload Test Plan from test memory (Note).
3. Print Test Plan directory.
4. Print Test Plan.
b. Origin: From the “Start-Up” menu (see Figure 14-1), press key 2 (SET UP), press key 4 (NEXT
PAGE), press key 4 (TEST PLAN).
c. Action Option: Press key 4 to print a test plan from memory.
Note:
The user unloads a Test Plan from test memory to clear the name-plate voltages loaded in memory.
