Model ATRT-03 (v) Operating Instruction
59
19-1. Scroll Test Record Menu:
RECORD ID INFO:
ONTARIO AIRPORT
220KV EAST
GE
Figure 19-1A. Scroll Test Record LCD Display First Screen
Note:
1. The second line of the Record ID Info displays the Substation Name.
2. The third line of the Record ID Info displays the Circuit Name.
3. The fourth line of the Record ID Info displays the Transformer Manufacturer Name.
4. The above transformer’s ID is shown as follows:
Substation: ONTARIO AIRPORT
Circuit: 220KV EAST
Mfr: GE
4. Use the “∧” or “∨” key advance to the next screen.
SINGLE PHASE XFORMER
2 TAPS
07/16/00 22:01:00
Figure 19-1B. Scroll Test Record LCD Display Second Screen
Note:
1. The first line of the screen displays the transformer type.
2. The second line of the screen displays the number of taps of the transformer.
3. The third line of the screen displays the date and time of the test.
4. Use the “∧” or “∨” key advance to the next screen.
