Model ATRT-03 (v) Operating Instruction
68
21.0 Load a Test Plan From Memory
Table 21-1 shows the steps to load a transformer test plan to run a transformer test. Transformer
test plan contains transformer test voltages. Calculated ratio (derived from transformer voltages) is
then compared with tested ratio for percentage error. A test report using test plan shows “PASS” or
“FAIL” results.
Table 21-1. Load A Test Plan from ATRT-03/03A/03B Memory
STEP DESCRIPTION DISPLAY ACTION
1 Select “Set Up” menu
1.TEST XFMR 04/12/00
2.SETUP 13:06:00
3.CALCULATOR
4.DIAGNOSTIC
Press key 2
2 Select “NEXT PAGE” menu
1.ENTER XFRMR ID
2.REVIEW RECORD
3.RESTORE RECORD
4.NEXT PAGE
Press key 4
3 Select “TEST PLAN” menu
1.COMPUTER CONTROL
2.SET TIME
3.SET TEST VOLTAGE
4.TEST PLANS
Press key 4
4 Select “LOAD TEST PLAN”
1.LOAD TEST PLAN
2.UNLOAD TEST PLAN
3.TST PLAN DIRECTORY
4.PRINT TEST PLAN
Press key 1
(LOAD TEST
PLAN)
5 Select Test Plan by Scrolling
LOAD TEST PLAN
1.ENTER PLAN NUMBER
2.SCROLL TO SELECT
Press key 2 to
select scroll.
6 Scroll forward to test plan
TEST PLAN DIRECTORY
“UP” to SCROLL FWD
“DWN” TO SCROLL RVS
Press “
∧
” key
7 Select test plan
2 SNG PHS TAPS:2
GE
12 445
JUST A TEST
Press “ENTER”
key
8 Test plan loaded from memory
1.TEST XFMR 04/12/00
2.SETUP 13:06:00
3. CALCULATOR
4.DIAGNOSTIC
