20.0 Print a Test Plan in Memory
The following paragraph is not applicable to the ATRT-03B.
Table 20-1 presents the steps to print a transformer test plan stored in the FLASH EEPROM.
Transformer test plan contains transformer test voltage at different taps. Calculated ratio (derived
from transformer voltages) is compared with the tested ratio for a percentage error. A transformer
test report containing test plans will show “PASS” or “FAIL” results.
Table 20-1. Print A Test Plan from ATRT-03/03A Memory
STEP DESCRIPTION DISPLAY ACTION
1 Select “Set Up” menu
1.TEST XFMR 04/12/00
2.SETUP 13:06:00
3 CALCULATOR
4.DIAGNOSTIC
Press key 2
2 Select “NEXT PAGE” menu
1.ENTER XFRMR ID
2.REVIEW RECORD
3.RESTORE RECORD
4.NEXT PAGE
Press key 4
3 Select “TEST PLAN” menu
1.COMPUTER CONTROL
2.SET TIME
3.SET TEST VOLTAGE
4.TEST PLANS
Press key 4
4 Select “PRINT TEST PLAN”
1.LOAD TEST PLAN
2.UNLOAD TEST PLAN
3.TST PLAN DIRECTORY
4.PRINT TEST PLAN
Press key 4
(PRINT TEST
PLAN)
5 Select Test Plan by Scrolling
PRINT TEST PLAN
1.ENTER PLAN NUMBER
2.SCROLL TO SELECT
Press key 2 to
select scroll.
6 Scroll forward to test plan
TEST PLAN DIRECTORY
“UP” to SCROLL FWD
“DWN” TO SCROLL RVS
Press “
∧
” key
7 Select test plan
(Note)
2V SNG PHS TAPS:5
WESTINGHOUSE
2000288
Voltage Reg Test Plan
Press “ENTER”
key
8 Test plan being printed on thermal
printer
1.TEST XFMR 04/12/00
2.SETUP 13:06:00
3.CALCULATOR
4.DIAGNOSTIC
None
Note:
1. A summary of transformer test plan is shown on the LCD.
2. Line #1 of the display indicates the test plan number, type of transformer, and number of taps.
3. Line #2 identifies the transformer manufacturer as WESTINGHOUSE.
4. Line #3 contains the transformer model is “2000288.”
5. Line #4 contains a comment the operator used in the test plan.
