Model ATRT-03 (v) Operating Instruction

Table 16-1. Three-Phase Transformer Test Procedure Steps (cont.)

STEP DESCRIPTION DISPLAY ACTION

14 Store reading into the buffer

KEEP THIS READING?

1YES

2.NO

Press key 1

15 End test

RUN ANOTHER TEST?

1.YES

2.NO

Press key 2

16 Store Test Results in FLASH EEPROM

SAVE THIS RECORD?

1.YES

2.NO

Press key 1

17 Test Results Saved in FLASH

EEPROM confirmation

RECORD NUMBER 3

HAS BEEN SAVED

Press any Key

18 Return to main menu

1.TEST XFMR 04/12/00

2.SETUP 13:06:02

3.CALCULATOR

4.DIAGNOSTIC

None
