Model ATRT-03 (v) Operating Instruction
84
27.0 ATRT-03/03A/03B Cable Test
The following steps allow the user to run diagnostics on the ATRT-03/03A/03B cables.
Table 27-1. ATRT-03/03A/03B Cable Diagnostic
STEP DESCRIPTION DISPLAY ACTION
1 Select “Diagnostic” menu
1.TEST XFMR 04/12/00
2.SETUP 13:06:00
3.CALCULATOR
4.DIAGNOSTIC
Press key 4
2 Select “Cable Test” menu
DIAGNOSTIC
1.CABLE TEST
2.VERIFICATION TEST
Press key 1
3 Connect cables
CABLE TEST
CONNECT: H0-X0, H1-X1
H2-X2, H3-X3
THEN “ENTER” KEY
Press
“ENTER” key
4 Observe test results
CABLE TEST
H0-X0, H1-X1: OK
H0-X0, H2-X2: OK
H0-X0, H3-X3: OK
Press any key
to return to
main menu
Note:
A failed diagnostic on the cable test will be showed as “NOT OK”.
