Vanguard Instruments ATRT-03 - Figure 22-1. Test Plan Identification Menu; Test Plan Identification Menu

Model ATRT-03 (v) Operating Instruction
72
22-1. Test Plan Identification Menu
2 SNG PHS TAPS:2
GE
12 445
JUST A TEST
Figure 22-1. Test Plan Identification Menu
a. Description: Test plan identification screen shows transformer type, transformer manufacturer,
transformer model, number of test on test plan and special note from the user.
The following information belongs to the test plan above:
1. The test plan above is the second test plan stored in memory.
2. Transformer type is “Single Phase”.
3. Transformer model is 12 445.
4. There are 2 taps (position) on this test plan.
5. Special user’s note is, “JUST A TEST”.
b. Origin: This menu is shown after the user selects a test plan from memory.
c. Action Option: After a test plan ID is shown on the screen, press “ENTER” key to use.
