General description
Connecting the CTC II to a tachograph
2.7 Connecting the CTC II to a tachograph
1 Use the diagnostic cable to connect the CTC II to the
calibration interface of the tachograph.
Refer to the information in the tachograph product manual
for guidance.
2 Connect the CTC II to the light barrier.
Connection to the light barrier is only required for measuring
on the road with the Automatic Measured Track!◄
Important
Access to the calibration interface of an activated
DTCO 1381, SmarTach
®
or SE5000 is only possible if a valid
workshop card is inserted and the tachograph is in the
"Calibration" operating mode.◄
Important
