CTC II • Edition 01/2009
A2C59512809 © Continental Trading GmbH 47
Device testing
Speed test (MTCO 1324, SE2400)
7.1 Speed test (MTCO 1324, SE2400)
Testing the accuracy of the speed indicator and the speed
recording on the tachograph chart (record sheet).
During a speed test, three points must be approached; these
points differ according to the upper limit of the measuring
range of the tachograph; see the following table.
This Chapter explains the possible functions available for
device testing using the CTC II.
Chapter 2.8 "Program overview (menu tree)" on Page 26 tells
you which functions are available for a connected
tachograph.◄
Important
Fig. 3: Speed test
Upper limit of the measuring range [km/h]
100 125 140 180
1. Measuring point [km/h] 27 … 30 37 … 40 37 … 40 57 … 60
Break 120 seconds
2. Measuring point [km/h] 57 … 60 77 … 80 77 … 80 97 … 100
Break 120 seconds
3. Measuring point [km/h] 87 … 90 117 … 120 117 … 120 157 … 160
Break 120 seconds
