CTC II • Edition 01/2009
A2C59512809 © Continental Trading GmbH 39
The steps involved in measuring and testing
Road measurement
6.1.1 Automatic Measured Track
1 Position the vehicle in front of the start reflector stand.
2 Press to start the "Automtic measuring track" menu.
The CTC II reads the tachograph type.
3 Drive along the measured track at a steady speed.
4 End of measurement. Continue program.
When the vehicle has been driven past the end reflector
stand, an acoustic tone sounds and the determined values
are displayed.
5 Press to adjust the K value to match the determined W value.
The CTC II programs the determined W value in the
tachograph.
Remark:
The K value may deviate by ± 2 imp/km from the determined
W value, due to electronic splitting.
6 End the program.
If the determined characteristic coefficient "W" deviates by
±1% from the set device constant, the K value must be
adjusted accordingly.◄
Important
