CTC II Error messages
Operating Instructions Invalid measuring value
76 © Continental Trading GmbH A2C59512809
12.2 Invalid measuring value
12.3 CTC II error messages
12.3.1 Roller measurement
6
The "V" and/ or "N" values are not saved in the
CTC II in ascending order.
Measures:
– Sort profile entries in ascending order.
Error message Cause/ Measure to correct error
! ERROR !
PROFILE INCONSISTENT
CONTINUE WITH KEY
Error message Cause/ Measure to correct error
Values outwith the value range.
! INVALID ENTRY !
VALID VALUES:
<Min> - <Max> <Unit>
CONTINUE WITH KEY
Error message Cause/ Measure to correct error
1
Test program speed is too low.
Measures:
– Increase vehicle speed.
– Increase vehicle speed to at least 3 km/h.
– Check diagnostic cable and replace if necessary.
– Check connections.
2
Test program speed is too high.
Measures:
– Reduce vehicle speed.
! ERROR !
SPEED TOO LOW
CONTINUE WITH KEY
! ERROR !
SPEED TOO HIGH
CONTINUE WITH KEY
