7-21
7 In-Tank Setup Line Manifolded Tank Status
Line Manifolded Tank Status
If necessary, press STEP until you see the message:
This entry tells the system which tanks are line manifolded together (see Figure 7-3), allowing the system to
provide cumulative volume information on product stored in a line manifolded tank set. You only need to enter this
information for one of the tanks in the line manifolded set. The system automatically enters the information for the
other tank (s) in the set. For example, if you are entering setup information for Tank #3 as shown in the figure, and
it is line manifolded with Tank #1 (itself in a siphon manifolded set), you would press CHANGE until 01 appears
(you would press the Right-Arrow key to move to the next field if another tank were in the line manifolded set, then
press CHANGE until that tank’s number appeared). Press ENTER when you are done making these changes.
Figure 7-3. Line Manifolding A Siphon Manifolded Set To A Single Tank
Leak Minimum Periodic
If necessary, press STEP until you see the message:
This value tells the system the minimum tank volume required to record a passed periodic test. The value reflects
federal, state, and local requirements.
Legend for numbered boxes:
1. To dispenser 4. T2
2. T1 5. T3
3. Pumps
T3: LINE MANIFOLDED
T#: 00,00,00,00,00,00,00
consoles\l&s.eps
1
3
2 4 5
T1: (Product Label)
LEAK MIN PERIODIC: 000%
To Next Page
