Veeder-Root TLS-300 System Setup Manual

Appendix C: Typical Setup Parameters - TLS-350
C-3
Table C-3. In-tank Setup
Parameter Default Set As
Product Label None
As Tank Product
(e.g. UL unleaded)
Product Code 1 to 8 Default
Thermal Coeff. 000000
0.00126 Spirit, 0.00300 LPG
0.00081 DV
Tank Diameter 00000 As Tank Diameter
Tank Profile 1 Point
1 Point Flat Ends
4 Point Shallow-dished Ends.
20 Point Hemispherical Ends.
Linear for Vertical Cylindrical & Rectangular Tanks
Full Volume 00000 100% Tank Volume
Point 2 00000 75% Tank Diameter
Point 3 00000 50% Tank Diameter
Point 4 00000 25% Tank Diameter
Meter Data No Yes
End Factor Other
Cal. Update Periodic Default (except select NEVER for Linear Tanks)
Float Size
101 mm (8496 and 8499
types) 50 or 76 mm (according to size fitted)
Water Warning 00.00 25.0 mm
Water Limit 00.0 32.0 mm
Label Vol. as 100% Vol. As Tank Label
Overfill Vol. 000% 99%
High Product 000%
98% if Label Volume >25,000 litres, or 96% if Label
Volume <25,000 litres
Delivery Limit 001% Default
Low Product:
Mag Type 8473
Mag Type 8493
00000
0000
Vol at 250 mm
Vol at 125 mm
Leak Alarm Limit 374 10 litres
Sudden Loss Limit 374 200 litres
Tank Tilt 0 10 mm
Manifold Tanks None Default*
