7 In-Tank Setup Full Volume
7-6
Linear
This method requires only the 100% (full) volume to profile the tank. When using the linear tank profile you must
enter the inside height of the tank in place of the inside diameter of the tank in Tank Diameter setup (see above).
This profile can be used for flat-ended cylindrical tanks standing on end and for rectangular tanks.
PROCEDURE
To accept the Tank Profile shown on the TANK PROFILE message, press STEP. (The system displays the FULL
VOL message.)
To change the Tank Profile, press CHANGE until the desired profile appears. Press ENTER to confirm your choice.
The system displays:
To accept the displayed tank profile, press STEP to continue. To select another tank profile, 4 pt, 20 pt, Linear, or
50 pt, press CHANGE until the desired profile is displayed:
Press ENTER:
If sure, press CHANGE:
Press ENTER to confirm:
Full Volume
If necessary, press STEP until you see the message:
To enter the full volume of the tank (100% height) press CHANGE. Enter the volume in gallons or litres, depending
on the units established in System Setup. Press ENTER to confirm your entry. The system displays:
T1: (Product Label)
TANK PROFILE 1PT
TANK PROFILE: XXXXXX
T1: (Product Label)
These messages appear when 50 pt profile is selected.
Changing profile selection will erase the previously
entered 50 point profile!
ARE YOU SURE? : NO
CLEAR EXISTING PROFILE
ARE YOU SURE? : YES
CLEAR EXISTING PROFILE
PRESS <STEP> TO CONTINUE
ARE YOU SURE? : YES
T1: (Product Label)
FULL VOL: 000000
FULL VOL: XXXXXX
PRESS <STEP> TO CONTINUE
