12 Volumetric Line Leak Detection Pump Pressure
12-4
Press STEP to display the message:
Use this display to enter the type of piping material of fiberglass, steel, 2-wall fiber (fiberglass), or flexible.
If the piping is made of steel, press STEP to continue, or press CHANGE until the correct piping material appears,
then press ENTER. The system confirms your choice with the message:
Press STEP to continue.
Pump Pressure
If necessary, press STEP until you see the message:
Use this display to enter the pump pressure in the pipeline.
To enter the pump pressure, press CHANGE. Enter the pump pressure to the nearest whole number. Refer to
Table 12-1 for nominal pressures:
Table 12-1. Submersible Pump Nominal Pressures
Pump Brand Model HP PSI KPA
Red Jacket P33R1 1/3 25 172
P75S1 3/4 27 186
P150S1 1-1/2 29 200
P200U1 2 45 310
X315OU1 1-1/2 43 297
Red Jacket
Big-Flo
P200H3-2MB 2 (2-stage) 44 304
P300H3-2HB 3 (2-stage) 34 237
P500H3-2K 5 (2-stage) 40 279
Tokheim 585-13 1/3 23 159
585-34 3/4 25 172
585-150 1-1/2 27 186
FE Petro STP33 1/3 27 186
STP75 3/4 30 207
STP150 1-1/2 33 228
FE Petro
Hi Capacity
STP3HP 3 33 229
STP5HP 5 39 272
P#: (Pipe Label)
PIPE TYPE: STEEL
PIPING TYPE: (Choice)
PRESS <STEP> TO CONTINUE
P#: (Pipe Label)
PUMP PSI:
