18-3
18 Liquid Sensor Setup Liquid Sensor Category (RS-232 and Remote Display)
Press ENTER to confirm your choice:
Press STEP to continue.
Liquid Sensor Category (RS-232 and Remote Display)
If necessary, press STEP until you see the message:
If necessary, press CHANGE until you see the correct category. Additional category options are:
• ANNULAR SPACE
1
• DISPENSER PAN
• MONITOR WELL
• STP SUMP
• PIPING SUMP
When you display the correct category, press ENTER.
1
International installations - Interstitial sensors to be configured under ANNULAR SPACE in the liquid sensor
category. Then upon alarm this sensor can only be cleared through the CONFIRM CLEAR function in the
Diagnostic Mode. This is feature is only available if HRM is enabled (ref. “TLS-350 Consoles” on page 4-1).
Setting Up Additional Liquid Sensors
If you have additional liquid sensors to configure, press STEP, if necessary, until you see the ENTER SENSOR
LOCATION message. Press TANK/SENSOR to select another sensor and follow the procedures described
above beginning with the section “Liquid Sensor Location” on page 18-2.
If you have entered setup information for all sensors, press FUNCTION to exit.
(Sensor Type)
PRESS <STEP> TO CONTINUE
L1:(Sensor Location)
CATEGORY : OTHER SENSORS
