Veeder-Root TLS-300 - Communication Side DIM Alarms; Smart Sensor Alarms; Pump Relay Monitor Alarm; VMCI Dispenser Interface Alarms

24-7
24 Output Relay Setup Assignment Method
COMMUNICATION SIDE DIM ALARMS
If necessary, press STEP until you see the message:
Select Communication Bay DIM Alarms (ref. Alarm List in Section 6, Table 6-2).
SMART SENSOR ALARMS
If necessary, press STEP until you see the message:
Select Smart Sensor Alarms (ref. Alarm List in Section 6, Table 6-2).
PUMP RELAY MONITOR ALARM
If necessary, press STEP until you see the message:
Select Pump Relay Monitor Alarm (ref. Alarm List in Section 6, Table 6-2).
When you have specified the assignment method for each Pump Relay Monitor Alarm condition, press STEP. If no
other sensor or inputs are configured, the system returns to the IN-TANK ALARMS message.
VMCI DISPENSER INTERFACE ALARMS
If necessary, press STEP until you see the message:
Select the VMCI Alarms to send (ref. Alarm List in Section 6, Table 6-2).
VMC ALARMS
If necessary, press STEP until you see the message:
Select the VMC Alarms to send (ref. Alarm List in Section 6, Table 6-2).
R1: (Name)
COMM SIDE DIM ALM: NO
R1: (Name)
PUMP RLY MON ALMS: NO
R1: (Name)
PUMP ALARM: NO
R1: (Destination)
VMCI ALARM: NO
R1: (Destination)
VMC ALARM: NO
