10-3
10 Pressurized Line Leak Detection User Defined Pipe Type - Setup Parameters
ENTERING LINE LENGTH FOR DUAL SIZE FLEXIBLE PIPE TYPES
If you are using Enviroflex PP1502/2502, Enviroflex PP1502/2503, or 1.5/2 IN Envirn Gflxd, your line length setup
will first display the 1.5 inch size:
Press CHANGE and enter the actual line length (rounded up to the next foot). Press ENTER to confirm your
choice and the line length setup for the 2.5 inch size appears:
Press CHANGE and enter the actual line length (rounded up to the next foot). Press ENTER to confirm your
choice and press STEP to continue.
ENTERING LINE LENGTH FOR 2.0/3.0 IN. FIBERGLASS PIPE TYPE
If you are using fiberglass, your line length setup will first display the 2.0 inch (50 mm) size:
Enter the actual line length (rounded up to the next foot) and press ENTER. If you are not using 2-inch fiberglass,
enter 0 and press ENTER. The display shows the 3-inch (76 mm) size:
If you are not using 3-inch line, enter 0 and press ENTER. If you are using 3-inch line, enter the length and press
ENTER.
IMPORTANT! When using the Fiberglass pipe type, the unused size’s length must be set to zero.
Press STEP to continue.
User Defined Pipe Type - Setup Parameters
If you selected User Defined as the pipe type, your 1st line length setup will display (If the line consists of one pipe
type, one diameter, ignore the second line length entry. If the line is constructed of two connected lengths of the
same pipe type but with different diameters, or of two connected lengths of different pipe types with the same or
different diameters, then enter the required second line’s data.):
Press CHANGE, enter the first line length (rounded up to the next foot) then press ENTER to confirm your choice.
Press STEP to continue.
Q1: (Pressure Line Label)
1.5 IN DIAM. LEN: 501
Q1: (Pressure Line Label)
LINE LENGTH: 301
Q1: (Pressure Line Label)
2.0 IN DIAM. LEN: 501
Q1: (Pressure Line Label)
3.0 IN DIAM. LEN: 351
Q1: (Pressure Line Label)
1ST LINE LENGTH: 501
Q1: (Pressure Line Label)
2ND LINE LENGTH: 0
