37 © VeEX Inc. All Rights Reserved. Ethernet
Results
l
Hop: Order of the routers on the route
l
TTL: Time to reach each router on the route
l
Address: Address of each router on the route
If there is no response from a particular hop, an asterisk will be displayed.
ARP Wiz
ARP Wiz uses the Address Resolution Protocol (ARP) to verify the status of each IP address in a user-select-
able IP range. ARP is the standard method for finding a host's hardware address when only its network layer
address is known. In other words, ARP is used primarily to translate IP addresses to Ethernet MAC addresses.
ARP is defined in RFC826.
ARP Setup
Configure the following parameters and press Start. The test will continue to run until Stop is pressed. A fin-
ished status indication will display when the test finishes.
l
Profile: Default, Delete, Save, or Save As...
l
Start IP: Starting IP Address.
l
End IP: Ending IP Address.
l
Time Out(s): Range from 1-99 seconds. Input using the numeric keypad.
