59 © VeEX Inc. All Rights Reserved. Ethernet
V-TEST - Results - Http Graphs
More about Link Statuses
Link Status Indicator Labels
A yellow status box will be displayed when the link has been properly established with the port
under test and it is considered active.
10GE: 10 Gbit/s, 10GBASE-T copper interface (RJ45 UTP) or 10GBASE-
X optical interface (LC-UPC duplex)
5GE: 5 Gbit/s, 5GBASE-T copper interface (RJ45 UTP) or 5GBASE-X
optical interface (LC-UPC duplex)
2.5GE: 2.5 Gbit/s, 2.5GBASE-T copper interface (RJ45 UTP) or
2.5GBASE-X optical interface (LC-UPC duplex)
1GE: 1 Gbit/s, 1GBASE-T copper interface (RJ45 UTP) or 1GBASE-
optical interface (LC-UPC duplex)
1000T: 1 Gbit/s, 1000BASE-T copper interface (RJ45 UTP)
100T: 100 Mbit/s, 100BASE-T copper interface (RJ45 UTP)
10T: 10 Mbit/s, 10BASE-T copper interface (RJ45 UTP)
FDX: Full Duplex
HDX: Half Duplex
UTP: Unshielded Twisted (copper) Pairs cable
V-FTP
