23 © VeEX Inc. All Rights Reserved. Basic Operation
Exit: Return to the previous screen.
Home: Return to the Home Menu.
Active Test Application: Access to test applications or test application menu which varies
depending on the test set mode. WiFi, SLM, FIBER, and OSA are some of the applications avail-
able.
Utilities Test Application: Opens the System Tools and Utilities menu.
Shift Key: Serve the same function of expanding the side menu bars as pushing the physical
side buttons on the sides of the unit. Tap to reveal/hide icons and test function keys.
AC Charging: The unit is plugged into external AC power. Tap to see battery charge status.
Battery Powered: The unit is powered by the battery. Tap to see battery charge status and
estimated autonomy time.
Fiberscope: Indicates that a fiberscope is connected to the unit. Tap the icon to go to the Fiber-
scope application.
LEDs
Soft LEDS are supported on several test modes:
Single Port LED Status Lights
