Summit & Summit 800
Feature Description and Operation Manual Issue 1.2
109
2. Press the {DOOR OPEN} button.
3. Hang-up to return to idle.
Conditions
1. The Summit has two External Control Contacts, one each located on the
Miscellaneous connector of the KSU and EKSU.
2. The Door Open feature dial code is based on the assigned External Contact as below:
External Contact 1 = “#*1”
External Contact 2 = “#*2”
3. The contacts are rated at 1 amp, 24 VDC.
4. A station will receive error tone if not allowed access to the Door Open feature (PGM
113-Button 24-2)
Programming
Keyset Admin.
YSTEM External Contact Control (PGM 168)
