Summit & Summit 800
Feature Description and Operation Manual Issue 1.2
418
7.4 SLT Message Wait Indication
Description
All SLT devices will receive a “Stutter” dial tone as an audible indication of a Message Waiting. In
addition, industry standard Message Waiting telephones may be connected to the system.
Software will cause the lamp to flash when a messaging is waiting.
Operation
System
The system switches the 90 VDC lamp On and Off for assigned SLTs indicating a Message
Wait.
Conditions
1. The system switches a 90 VDC supply On and Off to flash the SLT’s neon Message
lamp.
2. Although the SLT Battery Feed is removed during the 90 VDC On cycle, the system
will recognize an SLT Off-hook event.
3. The SLT must incorporate a 90 VDC neon lamp that is connected directly across the
tip and ring of the voice network.
Programming
Keyset Admin.
