The following table provides detailed information on the meaning and function of the various
SMDI action codes.
Table SMDI Messages
Action Code Reason Purpose Message Type
SMDI Message
MD 001 0001-
A Unconditional forward to VM Put Mail II A xxxxx yyyyy
B Called Station busy Busy Mail II B xxxxx yyyyy
C Disconnect, connected party disconnect II C xxxxx yyyyy
D Direct Fwd to VM group Get Mail II D xxxxx yyyyy
E Error, invalid number Error II E xxxxx yyyyy
H Two-way Record record II H xxxxx yyyyy
I DND DND II I xxxxx yyyyy
N No Answer No Answer II N xxxxx yyyyy
R Direct ring to VM group AA III R xxxxx yyyyy
Operation
System
The system will interface with the External AA/VM based on database assignments.
Conditions
1. Selection of SMDI or in-band signaling can be configured using Virtual Dip Switch
settings.
2. Only one AA/VM Group (Internal or External) can be defined in the system. Multiple
definitions will cause erroneous system operation.
Programming
Keyset Admin.
STATION GROUPS Station Group Assignment (PGM 190)
Station Group Attributes (PGM 191)
TABLES
Voice Mail Dialing Table (PGM 234)
DIP SWITCH
Virtual Dip Switch (PGM 453-Button 2)
Web Admin.
STATION GROUP
DATA
Station Group Assignment, Station Group Attributes
TABLES DATA
Voice Mail Dialing Table
MAINTENANCE
Trace

Virtual Dip Switch

SMDI Setting
