Summit & Summit 800
Feature Description and Operation Manual Issue 1.2
227
0: Other
The SMDR record output for internal calls is as shown in the figure and explained in the chart
below.
---- Site Name : --------------------------------------------------------------------------------------
STA CO TIME START DIALED
NUMBER
COST ACCOUNT
CODE
CPN
NUMBER
-------
-------
-------
---------------------
--------------
--------------
--------------
--------------
100
00:00:01
06/11/08 10:53
E100
105
00:00:00
06/11/08 14:13
S103
110
00:00:10
06/11/08 11:05
E Conf Rm 1
120
00:00:03
06/11/08 11:11
P123
STA
DIALED
Meaning
100 E101 1) Station 100 called station 101 and station 101 answered.
2) In a conference, station 100 was a conference master, station 101
was a conference member.
105
S103
Station 105 sent an internal SMS to station 103.
110
E Conf Rm 1
Station 110 was the member of conference room 1.
120
P123
Station 120 paged station 123.
Operation
System
For real-time SMDR, records are output after completion of the call as shown in the figures
above
System Attendant
To print SMDR records
1. Press the [TRANS/PGM] button.
2. Dial “0111”, the SMDR print code.
3. Enter the desired station range.
4. Press the [HOLD/SAVE] button.
To delete stored records
1. Press the [TRANS/PGM] button.
2. Dial “0112”, the SMDR delete code.
3. Enter the desired station range.
4. Press the [HOLD/SAVE] button.
To abort SMDR printing
1. Press the [TRANS/PGM] button.
2. Dial “0114”, the SMDR abort code.
3. Press the [HOLD/SAVE] button.
