Summit & Summit 800
Feature Description and Operation Manual Issue 1.2
347
05 – SLT MOH 2
06 – SLT MOH 3
07 – SLT MOH 4
08 – SLT MOH 5
09 – System Announcement MOH 2
10 – System Announcement MOH 3
4. Press [HOLD/SAVE] to save your selection.
Conditions
1. The speaker volume is adjustable at the station by using the [VOL UP]/[VOL DOWN]
buttons.
2. BGM is delayed 1 second after a return to idle state.
3. Silence is provided if no BGM source is assigned.
4. For remote devices, BGM must be locally provided; BGM is not sent from the Summit
system to remote devices.
5. System Announcement MOH 1 employs System announcement 071 and must be
recorded properly. System announcement MOH2 and MOH3 may use any unused
System announcement except for announcement 071 and 072. The announcement
number must be defined in the Music Sources program (PGM 171).
6. For SLT MOH, the SLT port must be connected properly and the station number of the
SLT port used for MOH must be assigned as the SLT MOH port.
Programming
Keyset Admin.
SYSTEM BGM Type (PGM 171-Button 1)
Internal MOH Type (PGM 171-Button 3)
Assign SLT MOH Port (PGM 171-Button 4)
VSF MOH2 (PGM 171-Button 5)
Related Features
MOH (Music-On-Hold)
Internal/External & All Call Page
Hardware
An external music source properly connected to the KSU, refer to the Summit
Hardwar Description and Installation Manual.
