REV : 5
REV DATE : 12/16
DPN001791
Page :1 /1
600mm (24in.) MODELS
Form No.: DPN001040_REV4
CABINET DIMENSIONAL DATA
LIEBERT CRV
AIR FILTERS
FRONT
REAR
ACCESS REQUIRED FOR INSTALLATION OF
THE LIEBERT CRV UNIT WITHIN THE ROW.
C
O
L
D
A
I
R
H
O
T
A
I
R
I
N
S
T
A
L
L
I
N
S
T
A
L
L
FRONT OR REAR CLEARANCE REQUIRED.
ACCESS REQUIRED TO SERVICE THE LIEBERT CRV UNIT WITHIN THE ROW
REAR SERVICE AREA IS S+B OR S+A WHEN B IS NOT AVAILABLE
TOP VIEW
12"
(305mm)
3 15/16"
100mm
Door Fully Open
B
S
S
A
13 3/4"
350mm
25 9/16"
650mm
46 1/4"
1175mm
27 9/16"
700mm
21 5/8"
550mm
107 5/16"
2725mm
25 9/16"
650mm
23 5/8"
600mm
3 15/16"
100mm
35 9/16"
903mm
FOR PROPER AIRFLOW DISTRIBUTION:
ALIGN THE FRONT DOOR OF NEIGHBORING
SERVER RACKS WITH THE FRONT CORNER
OF THE LIEBERT CRV.
78 3/4"
2000mm
NOMINAL
23 5/8"
600mm
46 1/4"
1175mm
3"
76mm
REAR VIEW
MODEL AIR COOLED WATER/GLYCOL CHILLED WATER
CR020R 739 (335) 772 (350)
CR035R 805 (365) 849 (385)
CR040R N/A N/A 728 (330)
DRY WEIGHT ±5% - Lbs (kg)
N/A
49"
1245mm
49"
1245mm
