Vertiv Liebert CRV - Evacuation, Leak-Testing, and Charging Air-Cooled Systems with Liebert Lee-Temp Flooded-Condenser Head-Pressure Control System

PRESSURE TEMPERATURE*
PSIG BARG °F °C
170 11.7 59.8 15.4
180 12.4 63.1 17.3
190 13.1 66.3 19.1
200 13.8 69.5 20.8
210 14.5 72.5 22.5
220 15.2 75.4 24.1
230 15.9 78.2 25.7
240 16.6 80.9 27.2
250 17.2 83.6 28.7
260 17.9 86.2 30.1
270 18.6 88.7 31.5
280 19.3 91.1 32.8
290 20.0 93.5 34.2
300 20.7 95.8 35.5
310 21.4 98.1 36.7
320 22.1 100.3 38.0
330 22.8 102.5 39.2
340 23.4 104.6 40.3
350 24.1 106.7 41.5
360 24.8 108.7 42.6
370 25.5 110.7 43.7
380 26.2 112.7 44.8
390 26.9 114.5 45.9
400 27.6 116.4 46.9
500 34.5 133.5 56.4
600 41.4 148.1 64.5
* Values are for saturated liquid
Source: DPN002411, Rev. 8
Table 6.12 Liquid pressure andtemperature chart
6.2.6 Evacuation, Leak-testing, and Charging Air-cooled Systems withLiebertLee-Temp
“Flooded-condenser” Head-pressureControlSystem
The Liebert Lee-Temp system consists of a modulating-type head-pressure control valve and insulated
receiver with heater pad to ensure operation at ambient temperatures as low as -30°F (-34.4°C). The
Liebert Lee-Temp system can be used with any compressor or expansion-valve choice.
A discharge line and liquid line must be field-installed between the indoor unit and the outdoor
condenser. See the appropriate piping schematic, listed in Table 6.1 on page33.
