2 NOMENCLATURE AND COMPONENTS
This section describes the model-number configuration for Liebert CRV units and components.
2.1 Model-number Nomenclature
The tables describe the 25-digitconfigurationnumber. The 14-digit model number consists of the first 10
digits and last 4 digits of the configuration number.
For the full description of configuration and model number refer to Model-number Nomenclature Detail
on page153.
MODEL NUMBER DIGITS 1 TO 10 MODEL DETAILS MODEL NUMBER DIGITS 11 TO 14
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25
C R 0 2 0 R A 1 C 7 S H 1 8 1 1 E L 1 0 P A — — —
Digits 1-2 - Unit Family Digit 14 - Air Filter
Digits 3-5 - Nominal Capacity, kW Digit 15 - Water/Glycol Valve Type
Digit 6 - Row-Based, Unit Depth Digit 16 - Enclosure
Digit 7 - System Type Digit 17 - High-Voltage Options
Digit 8 - Fan Type Digit 18 - Option Package
Digit 9 - Power Supply Digit 19 - Liebert IntelliSlot™ Housing
Digit 10 - Cooling System Digit 20 - Future Options
Digit 11 - Humidifier Digit 21 - Packaging With Ramp
Digit 12 - Control System Digit 22 - Special Features
Digit 13 - Reheat Digits 23-25 - Factory Configuration Number
2.2 Component Location
The unit component locations are described in the submittal documents included in the Submittal
Drawings on page156.
The following table lists the relevant documents by number and title.
DOCUMENT NUMBER TITLE
DPN003738 Component Locations, 600mm (24in.) Models
DPN003583 Component Location, 300mm (12in.) Air Cooled Models
DPN003585 Component Location, 300mm (12in.) Water Glycol Cooled Models
DPN003584 Component Location, 300mm (12in.) Chilled Water Models
Table 2.1 Component-location Drawings
