Figure 5.1 Caster locations
ITEM DESCRIPTION
1 Rear of 300-mm (12-in.) unit, bottom view
2 Rear of 600-mm (24-in.) unit, bottom view
3 Caster, 1 at each corner
4 Stabilizer, 1 at each corner
5 Adjustable leveling foot, 1 at each corner
Vertiv | Liebert CRV Installer/User Guide | 28
