5. Position the bracket over the holes in the Liebert CRV and the adjacent cabinet.
6. Insert and tighten the four screws.
Figure 5.4 Tie-down bracket on cabinets of the same height—300mm (12 in.)
ITEM DESCRIPTION
1 Top of adjacent cabinet
2 Rear of unit
3 Screw holes for tie-down brackets
4 Top of the unit
5 Front of the unit
6 Bracket
