LINE SIZE, O.D., IN. HOT GAS LIQUID
3/8 — 3.2 (1.4)
1/2 0.7 (0.3) 5.9 (2.7)
5/8 1.1 (0.5) 9.6 (4.3)
3/4 1.6 (0.7) 14.3 (6.4)
7/5 2.3 (1.0) 19.8 (8.8)
1-1/8 3.9 (1.7) 33.8 (15.1)
1-3/8 5.9 (2.6) 51.5 (23.0)
1-5/8 8.4 (3.7) —
Data based on 50°F Evap 15°F superheat 125°F SCT 10°F sub-cooling
Source: DPN003099 Rev. 0
Table 6.9 Interconnecting piping refrigerant charge
for R-410A, lbper 100ft (kgper30m)
SINGLE CIRCUIT, LB/CIRCUIT (KG/CIRCUIT)
CONDENSER MODELS CONDENSERS WITHOUT LIEBERT LEE-TEMP CONDENSERS WITH LIEBERT LEE-TEMP
MCS028 2.5 (1.2) 21.7 (9.8)
MCM040 3.5 (1.6) 22.7 (10.3)
MCM080 8.5 (3.8) 39.8 (18.1)
MCL055 5.0 (2.3) 24.2 (11.0)
MCL110 10.7 (4.9) 49.1 (22.3)
Table 6.10 Liebert MC condenser refrigerant charge
approximateR-410AwithandwithoutLiebertLee-Temp
