Figure 7.2 Remove electrical panel and lower front panel—600 mm (24 in.)
ITEM DESCRIPTION
1 Bolts to remove for access to high-voltage electrical panel
2 Bolts to remove for access to low-voltage electrical panel
3 Bolts to remove to open lower front-baffle panel
