Vertiv NetSure 7100 Series Installation Manual

Vertiv | NetSure 7100 Series -48V DC Power System Installation Manual (IM582127000) | Rev. BB
104
Table 6: Nominal 208 VAC / 240 VAC Input Connections (Single-Phase) to a 588705000 List 31 and
588705500 List 03 Module Mounting Assembly
Module Mounting Assembly
Left Side as
Viewed from Rear
208 VAC, 240 VAC, 277 VAC Service
Type:
Line to Line:
Connect Line 1 to Terminal 1.
Connect Line 2 to Terminal 2.
Line to Neutral:
Connect Line to Terminal 1.
Connect Neutral to Terminal 2.
Right Side as
Viewed from Rear
PCU 4
1 1
PCU 1
2 2
PCU 5
1 1
PCU 2
2 2
PCU 6
1 1
PCU 3
2 2
