Vertiv | NetSure 7100 Series -48V DC Power System Installation Manual (IM582127000) | Rev. BB
146
Figure 68:
Bay-to-Bay Communications Cable Connections (cont’d on next page)
Main Bay 1st
Supplemental
Bay
2nd to 6th
Supplemental
Bays
Front doors remove in
illustration for clarity only.
(Continued on next page)
