Table 15 shows the menu navigation for some basic settings. Refer to the separate NCU Manual
(UM1M830BNA) supplied with your power system for complete Local Display menus.
NOTE! If an NCU configuration is furnished that enables NCU capability to receive status information
sent from Fiamm SoNick (Sodium Nickel) batteries, some NCU parameters cannot be changed. Refer to
the NCU controller manual UM1M830BNA for details.
Table 15: NCU Basic Settings Menu Navigation
Parameter Menu Navigation
Date
Main Menu / Settings Icon / Sys Settings / Date.
Time
Main Menu / Settings Icon / Sys Settings / Time.
IP Communications
Parameters
(IP address, subnet mask
address, gateway address)
Main Menu / Settings Icon / Comm Settings / enter parameters.
Float Voltage
Main Menu / Settings Icon / Batt Settings / Charge / Float Voltage.
Equalize Voltage
Main Menu / Settings Icon / Batt Settings / Charge / EQ Voltage.
Battery Capacity
Main Menu / Settings Icon / Batt Settings / Batt1 Settings or Batt2
Settings / Rated Capacity.
Battery Charge Temperature
Compensation
Main Menu / Settings Icon / Batt Settings / Temp Comp (enter
parameters).
Rectifier Current Limit
Main Menu / Settings Icon / Rect Settings / Current Limit (set to
enabled) then set Curr Limit Pt.
Over Voltage Alarm 1
Main Menu / Settings Icon / Other Settings / Over Voltage 1.
Over Voltage Alarm 2
Main Menu / Settings Icon / Other Settings / Over Voltage 2.
Under Voltage Alarm 1
Main Menu / Settings Icon / Other Settings / Under Voltage 1.
Under Voltage Alarm 2
Main Menu / Settings Icon / Other Settings / Under Voltage 2.
