Vertiv NetSure 7100 Series Installation Manual

Vertiv | NetSure 7100 Series -48V DC Power System Installation Manual (IM582127000) | Rev. BB
42
Figure 17: Installing a Battery Tray Mounting Kit P/N 565004 (cont’d from next page)
9. Mount the AC guard to the cabinet.
10. Remove the existing AC guard if the power system
distribution is shorter than 4-row. Save 8-32 x 3/8
screws.
11. Install AC guards provided with kit and saved
8-32 x 3/8 screws.
12. Torque to 20 in-lbs.
